配置IPv6安全邻居发现示例

2025-6-25

配置IPv6安全邻居发现示例

组网需求

如图1所示，为了提高网络中设备SwitchA的安全性，在SwitchA上配置了IPv6安全邻居发现功能。这样当网络中未配置IPv6安全邻居发现的设备SwitchB向SwitchA发送报文时，SwitchA将该报文视为非法报文而丢弃。

图1 配置IPv6安全邻居发现功能组网图
配置IPv6安全邻居发现示例

配置思路

采用如下的思路配置IPv6安全邻居发现功能：

  1. 在SwitchA上配置CGA类型的IPv6地址和普通IPv6地址。
  2. 在SwitchA上使能接口的严格安全模式功能。
  3. 在SwitchB上配置接口的IPv6地址。

操作步骤

  1. 配置SwitchA的CGA类型的IPv6地址
    <HUAWEI> system-view
[~HUAWEI] sysname SwitchA
[*HUAWEI] commit
[~SwitchA] rsa key-pair label switch
[*SwitchA] interface 10ge 1/0/1
[*SwitchA-10GE1/0/1] undo portswitch
[*SwitchA-10GE1/0/1] ipv6 enable
[*SwitchA-10GE1/0/1] ipv6 security rsakey-pair switch
[*SwitchA-10GE1/0/1] ipv6 security modifier sec-level 1
[*SwitchA-10GE1/0/1] ipv6 address fe80::3 link-local cga
[*SwitchA-10GE1/0/1] ipv6 address fc00:2::/64 cga
[*SwitchA-10GE1/0/1] ipv6 address fc00:1::1/64



  2. 使能SwitchA接口的严格安全模式功能
    [*SwitchA-10GE1/0/1] ipv6 nd security strict
[*SwitchA-10GE1/0/1] commit



  3. 配置SwitchB的IPv6地址
    <HUAWEI> system-view
[~HUAWEI] sysname SwitchB
[*HUAWEI] commit
[~SwitchB] interface 10ge 1/0/1
[~SwitchB-10GE1/0/1] undo portswitch
[*SwitchB-10GE1/0/1] ipv6 enable
[*SwitchB-10GE1/0/1] ipv6 address auto link-local
[*SwitchB-10GE1/0/1] ipv6 address fc00:2::2/64
[*SwitchB-10GE1/0/1] ipv6 address fc00:1::2/64
[*SwitchB-10GE1/0/1] commit



  4. 验证配置结果

    如果配置成功，可以查看配置的IPv6地址，以及接口状态为Up，IPv6协议状态为Up，IPv6安全邻居发现功能配置信息。

    # 显示SwitchA的10GE1/0/1接口的信息。

    [~SwitchA-10GE1/0/1] display this ipv6 interface
10GE1/0/1 current state : UP
IPv6 protocol current state : UP
IPv6 is enabled, link-local address is FE80::3057:B5D6:6BD6:6CA8
  Global unicast address(es):
    FC00:1::1, subnet is FC00:1::/64
    FC00:2::2092:84CE:827B:D5A4, subnet is FC00:2::/64
  Joined group address(es):
    FF02::1:FF00:1
    FF02::1:FF7B:D5A4
    FF02::1:FFD6:6CA8
    FF02::2
    FF02::1
  MTU is 1500 bytes
  ND DAD is enabled, number of DAD attempts: 1
  ND reachable time is 1200000 milliseconds
  ND retransmit interval is 1000 milliseconds
  Hosts use stateless autoconfig for addresses

    # 显示SwitchA的10GE1/0/1接口的IPv6安全邻居发现功能的配置信息。

    [~SwitchA-10GE1/0/1] display ipv6 security interface 10ge 1/0/1
 (L) : Link local address
 SEND: Security ND
 SEND information for the interface : 10GE1/0/1
----------------------------------------------------------------------------
 IPv6 address                                   PrefixLength Collision Count
----------------------------------------------------------------------------
 FE80::3057:B5D6:6BD6:6CA8 (L)                  10           0
 FC00:2::2092:84CE:827B:D5A4                    64           0
----------------------------------------------------------------------------
 SEND sec value : 1
 SEND security modifier value : 585D:9EA0:328:2792:B763:1DE3:BBC4:D22D
 SEND RSA key label bound : switch
 SEND ND minimum key length value : 512
 SEND ND maximum key length value : 2048
 SEND ND Timestamp delta value : 300
 SEND ND Timestamp fuzz value : 1
 SEND ND Timestamp drift value : 1
 SEND ND fully secured mode : enable

    # 显示SwitchB的10GE1/0/1接口的信息。

    [~SwitchB-10GE1/0/1] display this ipv6 interface
10GE1/0/1 current state : UP
IPv6 protocol current state : UP
IPv6 is enabled, link-local address is FE80::2E0:E6FF:FE13:8100
  Global unicast address(es):
    FC00:1::2, subnet is FC00:1::/64
    FC00:2::2, subnet is FC00:2::/64
  Joined group address(es):
    FF02::1:FF00:2
    FF02::1:FF13:8100
    FF02::2
    FF02::1
  MTU is 1500 bytes
  ND DAD is enabled, number of DAD attempts: 1
  ND reachable time is 1200000 milliseconds
  ND retransmit interval is 1000 milliseconds
  Hosts use stateless autoconfig for addresses

    # 从SwitchB ping SwitchA的CGA类型的链路本地地址，由于SwitchA配置了IPv6安全邻居发现功能，无法ping通。

    [~SwitchB-10GE1/0/1] ping ipv6 FE80::3057:B5D6:6BD6:6CA8 -i 10ge 1/0/1
  PING FE80::3057:B5D6:6BD6:6CA8 : 56  data bytes, press CTRL_C to break
    Request time out
    Request time out
    Request time out
    Request time out
    Request time out

  --- FE80::3057:B5D6:6BD6:6CA8 ping statistics ---
    5 packet(s) transmitted
    0 packet(s) received
    100.00% packet loss
    round-trip min/avg/max = 0/0/0 ms

    # 从SwitchB ping SwitchA的CGA类型的全球单播地址，由于SwitchA配置了IPv6安全邻居发现功能，无法ping通。

    [~SwitchB-10GE1/0/1] ping ipv6 FC00:2::2092:84CE:827B:D5A4
  PING FC00:2::2092:84CE:827B:D5A4 : 56  data bytes, press CTRL_C to break
    Request time out
    Request time out
    Request time out
    Request time out
    Request time out

  --- FC00:2::2092:84CE:827B:D5A4 ping statistics ---
    5 packet(s) transmitted
    0 packet(s) received
    100.00% packet loss
    round-trip min/avg/max = 0/0/0 ms

    # 从SwitchB ping SwitchA的普通全球单播地址，由于SwitchA配置了IPv6安全邻居发现功能，也无法ping通。

    [~SwitchB-10GE1/0/1] ping ipv6 FC00:1::1
  PING FC00:1::1 : 56  data bytes, press CTRL_C to break
    Request time out
    Request time out
    Request time out
    Request time out
    Request time out

  --- FC00:1::1 ping statistics ---
    5 packet(s) transmitted
    0 packet(s) received
    100.00% packet loss
    round-trip min/avg/max = 0/0/0 ms

    # 去使能SwitchA的IPv6安全邻居发现功能后，从SwitchB ping SwitchA的IPv6地址，可以ping通。以ping SwitchA的CGA类型的全球单播地址为例。

    [~SwitchA-10GE1/0/1] undo ipv6 nd security strict
[*SwitchA-10GE1/0/1] commit
    [~SwitchB-10GE1/0/1] ping ipv6 FC00:2::2092:84CE:827B:D5A4
  PING FC00:2::2092:84CE:827B:D5A4 : 56  data bytes, press CTRL_C to break
    Reply from FC00:2::2092:84CE:827B:D5A4
    bytes=56 Sequence=1 hop limit=64  time = 1 ms
    Reply from FC00:2::2092:84CE:827B:D5A4
    bytes=56 Sequence=2 hop limit=64  time = 20 ms
    Reply from FC00:2::2092:84CE:827B:D5A4
    bytes=56 Sequence=3 hop limit=64  time = 1 ms
    Reply from FC00:2::2092:84CE:827B:D5A4
    bytes=56 Sequence=4 hop limit=64  time = 1 ms
    Reply from FC00:2::2092:84CE:827B:D5A4
    bytes=56 Sequence=5 hop limit=64  time = 1 ms

  --- FC00:2::2092:84CE:827B:D5A4 ping statistics ---
    5 packet(s) transmitted
    5 packet(s) received
    0.00% packet loss
    round-trip min/avg/max = 1/4/20 ms



配置文件

  • SwitchA的配置文件
    #
sysname SwitchA
#
interface 10GE1/0/1
 undo portswitch
 ipv6 enable
 ipv6 security rsakey-pair switch
 ipv6 security modifier sec-level 1
 ipv6 address FC00:1::1/64
 ipv6 address FC00:2::/64 cga
 ipv6 address FE80::3 link-local cga
 ipv6 nd security strict
#
return
  • SwitchB的配置文件
    #
sysname SwitchB
#
interface 10GE1/0/1
 undo portswitch
 ipv6 enable
 ipv6 address FC00:1::2/64
 ipv6 address FC00:2::2/64
 ipv6 address auto link-local
#
return
